CGNS mesh repository

D 23 May 2009

List of CGNS files
image	Description
	Forward step multiblock-like mesh forwstep-st hybrid (tri/quad) mesh forwstep-hyb unstructured (quad) mesh forwstep-quad
	Pyramid obstacle hybrid tri/quad mesh: diam1, diam2, diam4, diam8 tri mesh: diam2-tri unstructured quad mesh (see picture): diam1-quad, diam2-quad structured like quad mesh: diam2-st, diam4-st, diam8-st Suffixes 1, 2, 4 and 8 respectively indicate the following respective approximate number of elements: 4500, 18k, 70k, 300k.
	10° Wedge in Channel channelwedge10tri (from Fluent export): 1792 tri with solution
